Mechanical Seals
1000 Series
Simple, Robust, Proven
A single cartridge flexible stator design for most ANSI and DIN pumps, adaptable to many other pumps and rotating equipment, and capable of handling the most demanding services in a standard stuffing box.
The Foundation of the FSI Product Line
The FSI Type 1030 is a simple, proven, robust design that makes up the foundation of the FSI product line. This single cartridge flexible stator design is perfect for industrial use with most ANSI and DIN pumps. This versatile design can be adapted for use in many other pumps and other rotating equipment. It is capable of handling the most demanding services and fits standard pump stuffing boxes without modification. It is also designed to fit big bore seal chambers.
The multi-spring stationary design of the FSI Type 1030 with its monolithic faces can compensate for misalignment between the pump housing and the rotating shaft. The springs and pins are located outside of the process to avoid clogging while the dynamic O-ring moves over a clean area as the stationary face wears, eliminating the potential for O-ring hang-up. The FSI 1030 is hydraulically balanced for cooler, longer running operation. The rotating face is shrouded in a stainless steel carrier, virtually eliminating breakage under excessive conditions.
The FSI Type 1030 Cartridge is easy to install. The setting clips position the cartridge axially, concentrically, and with proper perpendicularity to the equipment. The recessed gasket area eliminates the opportunity for extrusion and a large flush port is suitable for API Plan 11, 13, or 32 operations. As with all our seals, the FSI Series 1015 is factory preset to eliminate installation errors and pressure tested to ensure greater sealing reliability for your application.
The FSI Type 1040 incorporates all of the design features and advantages of the Type 1030 and includes additional ports for quench and drain connections. In conjunction with the quench and drain ports, a close clearance throttle bushing is included. Options for other auxiliary restrictive devices include customer designed lip seals, bronze labyrinth bushings, and die formed packing.
* As always, consult your ASI Representative for applications which approach or exceed these parameters.
** Premium materials are available upon request.
Why the 1000 Series Runs Longer
Multi-Spring Stationary Design
Monolithic faces compensate for misalignment between the pump housing and the rotating shaft.
Springs and Pins Outside the Process
Located away from the product to avoid clogging, so the seal keeps running in dirty service.
No O-Ring Hang-Up
The dynamic O-ring moves over a clean area as the stationary face wears.
Hydraulically Balanced
Balanced design runs cooler and longer under pressure.
Shrouded Rotating Face
Rotating face is held in a stainless steel carrier, virtually eliminating breakage under excessive conditions.
Easy Cartridge Installation
Setting clips position the cartridge axially, concentrically, and perpendicular to the equipment.
Recessed Gasket Area
Eliminates the opportunity for gasket extrusion.
Large Flush Port
Suitable for API Plan 11, 13, or 32 operation.
Factory Preset and Pressure Tested
Every cartridge ships preset to eliminate installation errors and pressure tested for reliability.
Type 1030 or Type 1040
The baseline single cartridge flexible stator seal for ANSI and DIN pumps and most rotating equipment. Fits standard stuffing boxes without modification and big bore seal chambers.
- Single flush port for API Plan 11, 13, or 32
- Multi-spring stationary, hydraulically balanced
- Factory preset and pressure tested
Everything in the Type 1030 plus additional quench and drain ports and a close clearance throttle bushing for services that need atmospheric side containment or cooling.
- Quench and drain connections
- Close clearance throttle bushing included
- Optional lip seals, bronze labyrinth bushings, or die formed packing
